Hitec 39380 HSB-9380TH Digital HV Brushless High Torque Servo
AUD $379.00
In stock
SKU
hrc39380
Features
- Programmable 12Bit PWM Digital Amplifier
- Custom Long Life Brushless Motor
- 1M Cycle Long Life Potentiometer
- Constant Output Torque
- Wide Operating Voltage (5 ~ 9 Volts DC)
- Dual Ball Bearing Supported Output Shaft
- Dust Resistant and Splash Proof Case
- 25Tooth Output Spline
- Hybrid Nylon Reinforced Plastic and Aluminum Case
- Low Power Consumption
Specs
- Operating Voltage Range (Volts DC) 6.0V ~ 7.4V
- Speed (Second @ 60°) 0.17 ~ 0.14
- Maximum Torque Range oz. / in. 472
- Maximum Torque Range kg. / cm. 34
- Current Draw at Idle 27 mA
- No Load Operating Current Draw 250 mA
- Stall Current Draw 2,100 mA
- Dead Band Width 1 µs
- Dimensions (Metric) 40.0 x 20.0 x 38.0
- Weight (Gram) 68
- Circuit Type EBL Digital
- Motor Type NeuCastle Brushless
- Gear Material Titanium
- Bearing Type Dual Ball Bearing
- Output Shaft (type / Ømm) H25T
- Case Material Plastic / Aluminum
- Dust / Water Resistance Splash Proof
- Connector Gauge (AWG) / Strand Count 20 / 80
| Product Name | Hitec 39380 HSB-9380TH Digital HV Brushless High Torque Servo |
|---|---|
| SKU | hrc39380 |
| Weight (lbs) | 0.200000 |
| Description | Features
Specs
|
