Hobbywing 30113304 XERUN Brushless ESC XR8 Plus G2S for 1/8 Scale

SPECIFICATIONS:

Cont./Peak Current      200A/1080A

Input Voltage               2-6S Lipo

BEC Output 6-8.4V Adjustable, Continuous/Peak Current: 6A/15A(Switch-mode)

Wires & Connectors      Black-11AWG-200mm*2

Output Wires                Black-11AWG-200mm*3

Input Connectors          No

Output Connectors        No

Fan Size                       30x30x10mm

Voltage Range               5-8.4V

Powered by BEC

ESC Programing via SET Button on ESC   Not Supported

LED Program Box                                   Not Supported

LCD Program Box                                  Supported

OTA Programmer                                   Supported

Programming Port            Independent programming port

Firmware                        Firmware Upgrade Supported

Size               56.1mmx42.1mmx38.5mm

Weight            122g(w/wires)

Applications      SL BL Motors
                       SD BL Motors

Vehicles            1/8^th On-Road/Off-Road/Truggy Racing

KV Rating/T Count       4S LiPo： 4268/4274≤3000KV
                                  6S LiPo：4274≤2400KV
