OS 51010915 OMA-3815-1000 38mm BRUSHLESS MOTOR (1000 RPV)
AUD $90.00
In stock
SKU
os-51010915
High-Powered Brushless Aircraft Motors from O.S.!
OMA-3815-1000 38mm BRUSHLESS MOTOR (1000 RPV) EQUIV .15 SIZE 2 STROKE
SPECIFICATIONS:
- Outside Diameter: 37mm
-Male connector 3.5mm
- Body Length: 37.8mm
- Poles: 14
- Shaft Diameter: 5mm
- Shaft Length: 11.7mm
- Weight: 130g
- Lead Wire Length: 50mm
- Lead Wire Gauge: 17AWG
- Male Connector: 3.5mm
- Rated Voltage: 11.1V
- Rated Current: 35A
- Maximum Current: 45A
-Power output max 499w
- No-Load Current: 1.1A
- Phase Resistance: 36.5mΩ
- Phase Inductance: 23.8uH
- Maximum Efficiency: 85%
- KV: 1000rpm/V
- Turns: 16T
| Product Name | OS 51010915 OMA-3815-1000 38mm BRUSHLESS MOTOR (1000 RPV) |
|---|---|
| Description | High-Powered Brushless Aircraft Motors from O.S.!OMA-3815-1000 38mm BRUSHLESS MOTOR (1000 RPV) EQUIV .15 SIZE 2 STROKE SPECIFICATIONS: - Outside Diameter: 37mm -Male connector 3.5mm - Body Length: 37.8mm - Poles: 14 - Shaft Diameter: 5mm - Shaft Length: 11.7mm - Weight: 130g - Lead Wire Length: 50mm - Lead Wire Gauge: 17AWG - Male Connector: 3.5mm - Rated Voltage: 11.1V - Rated Current: 35A - Maximum Current: 45A -Power output max 499w - No-Load Current: 1.1A - Phase Resistance: 36.5mΩ - Phase Inductance: 23.8uH - Maximum Efficiency: 85% - KV: 1000rpm/V - Turns: 16T |
| SKU | os-51010915 |
| Weight (lbs) | 0.500000 |
