Traxxas 3018R XL-5 ESC waterproof
AUD $99.00
In stock
SKU
trx-3018r
XL-5 Electronic Speed Control, waterproof
(land version, low-voltage detection (LVD), fwd/rev/brake)
FEATURES:
(land version, low-voltage detection (LVD), fwd/rev/brake)
FEATURES:
- Built-in two-stage low voltage detection (LVD)
for Lithium Polymer (LiPo) battery use - Innovative watersealed design
- 15-turn motor limit for 540 size motors
- 12-turn motor limit for 550 size motors
- Fully-proportional forward, reverse, and braking control
- Programmable with three drive profiles:
- Sport Mode – Fwd / Brake / Rev
- Race Mode – Fwd / Brake
- Training Mode – 50% Fwd / Brake / 50% Rev
- EZ-Set® push-button setup
- Multi-color LED
- Thermal shutdown protection
- Efficient, low-loss MOSFET design
- High-capacity heat sink
- Smooth, high-frequency operation
- Easy installation in Traxxas models
SPECIFICATIONS:
| Input voltage: | | 4-8 Cells (4.8 to 9.6 Volts DC) |
| Case Size: | | 1.23"W x 2.18"D x 0.61" H |
| Weight: | | 2.44 Ounce |
| Motor Limit: | | 15-turns** (540 Size) 12-turns** (550 Size) |
| On Resistance Forward: | | 0.007 Ohms |
| On Resistance Reverse: | | 0.014 Ohms |
| Peak Current - Forward: | | 100A |
| Peak Current - Reverse: | | 60A |
| Braking Current: | | 60A |
| Continuous Current: | | 14A |
| BEC Voltage: | | 6.0 VDC |
| BEC Current: | | 1A |
| Power Wire: | | 14 Gauge / 5" |
| Input Harness Wire: | | 26 Gauge / 9" |
| Transistor Type: | | MOSFET |
| PWM Frequency: | | 1600 Hz |
| Low Voltage Detection (LVD): | | 2-Stage indicators, switchable (on or off) |
| Thermal Protection: | | Thermal shutdown |
| Profile selection: | | Sport Mode: 100% FWD, 100% brakes, 100% REV Race Mode: 100% FWD, 100% brakes, no REV Training Mode: 50% FWD, 100% brakes, 50% REV |
| Single-button setup: | | Yes, Traxxas EZ-Set® |
| | | **Properly geared |
| Product Name | Traxxas 3018R XL-5 ESC waterproof | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Description | XL-5 Electronic Speed Control, waterproof (land version, low-voltage detection (LVD), fwd/rev/brake) FEATURES:
SPECIFICATIONS:
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SKU | trx-3018r | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Weight (lbs) | 0.200000 |
